3 Description
BOWA-IFU-11779-ARC400-V2.1.0-S0-EN Operating Manual ARC 400 27
3.4.2. MAQUET TEGRIS:
When you couple the HF device to an OR system:
 Correct coupling of the OR system and the HF device can be checked
with the “sign of life”(status icon).
The following states are signaled:
1. On the ARC 400 the connection to TEGRIS is enabled. There is no
connection to the OR system.
2. On the ARC 400 the connection to TEGRIS is enabled. There is a
correct connection to the OR system. The device can be adjusted from the
OR system. The white bar sweeps cyclically from left to right.
…
