5 Operation
88 Operating Manual ARC 400 BOWA-IFU-11779-ARC400-V2.1.0-S0-EN
5.10.9. Socket extension
The bottom bipolar socket can be extended. This allows a total of three
bipolar instruments to be connected.
With socket extension active, it is only possible to work with two bipolar
ERBE plugs on the bottom bipolar socket.
Autostart mode is not available on the extended top socket.
Select “Socket configuration” to access the socket extension screen.
Bild 5-28: Menu "Socket configuration"
Select socket extension for the bottom bipolar socket by touching the
right-hand selection area next to the two individual plugs.
Press “OK” to confirm your selection.
Press “Back” to return to the main screen.
Bild 5-29: Menu "Socket extension"
