Bowa ARC 400 - Components Required for Operation

3 Description
BOWA-IFU-11779-ARC400-V2.1.0-S0-EN Operating Manual ARC 400 25
3.4. Components required for operation
 Power cable
 Foot switch
 Neutral electrode for monopolar applications
 Connection cable for neutral electrode or instrument
 Instrument (monopolar or bipolar)
 Dr. Dongle as an individual memory stick
3.4.1. OR1 Storz
When you couple the HF device to an OR system:
 Correct coupling of the OR system and the HF device can be checked
with the “sign of life” (status icon).
The following states are signalled:
1. On the ARC 400 the connection to OR1 is enabled. There is no
connection to the OR system.
2. On the ARC 400 the connection to OR1 is enabled. There is a
correct connection to the OR system. The device can be adjusted from the
OR system. The white bar sweeps cyclically from left to right.
