5 Operation
46 Operating Manual ARC 400 BOWA-IFU-11779-ARC400-V2.1.0-S0-EN
The following pedal icons can be differed:
Icon / Button
Description
Icon / Button
Description
Icon / Button
Description
Double pedal
foot switch CUT
active
Double pedal
foot switch CUT
active not
connected
Double pedal
foot switch CUT
inactive
Double pedal
foot switch not
connected
Deactivate foot
switch CUT
Deactivate foot
switch COAG
Double pedal
foot switch
COAG active
Double pedal
foot switch
COAG active not
connected
Double pedal
foot switch
COAG inactive
Double pedal
foot switch not
connected
Single pedal foot
switch not
connected
Single pedal
foot switch
COAG inactive
Single pedal
foot switch
COAG active
Single pedal foot
switch COAG
active not
connected
Double pedal
ZAP Mode
COAG active
Double pedal
ZAP Mode
COAG inactive
Single pedal
ZAP Mode
COAG active
Single pedal
ZAP Mode
COAG inactive
Double pedal
ZAP Mode CUT
active
Double pedal
ZAP Mode CUT
inactive
