5 Operation
48 Operating Manual ARC 400 BOWA-IFU-11779-ARC400-V2.1.0-S0-EN
According to the contact quality, several icons are shown for neutral
electrodes:
Icon / Button
Description
Icon / Button
Description
Split neutral
electrode contact
quality OK
Non split neutral
electrode contact
quality OK
Split neutral
electrode contact
quality not
optimum
Non split neutral
electrode not
detected or
contact quality
insufficient
Split neutral
electrode contact
quality insufficient
Non split neutral
electrode not
connected /
recognised
Split neutral
electrode not
connected /
recognised
Display contact
quality
Split baby neutral
electrode contact
quality OK
Split baby neutral
electrode contact
quality not
optimum
Split baby neutral
electrode contact
quality insufficient
Split baby neutral
electrode not
connected /
recognised
