Installation & Connection
How to install
02
01 Unpack the GIFT BOX.
02 Detach the unit from the Half Sleeve.
03 Remove the safety screw for
Transporting which is on the top of
the unit.
*
Remove the protection unit
(support panel).
(Sticker : "You must remove it before
you install" )
Helf Sleeve
04 Screw a not provided to the right and left
side of the set.
05 Screw the Dash board.
06 Install the set and then install the
Trim Plate (option).
Screw : P/H M5.0mm X 8.0mm 8ea
Bord
Bracket Screw
Screw
