Specifications
GENERAL
Rated power source : 14.4V DC (allowable voltage range : 10V to 16V DC)
Grounging system : Negative type
Max.current consumption : 10.0A
Dimensions (W x H x D)
* Chassis : 178mm x 100mm x 152mm (7in x 3 9in x 6in)
* Nose : 178mm x 100mm x 40mm (7in x 3.9in x 1.6in)
* Weight : 2.65Kg (5.8lbs)
NAVIGATION
GPS Receiver:
* System : Sirf III GPS (Global Positioning System)
* Reception system : 12-channel multi-channel reception system
* Reception frequency : L1, 1575.42MHz
* Baud Rate : 9.6Kbps
* C/A Code : 1 023MHz chip rate
GPS antenna:
* Antenna : Ceramic latch
* Antenna cable : 3m(2 5ø stereo 4)
* Dimensions (H x V x W) : 53mm x 46.7mm x 14.1mm
DISPLAY
Screen size/aspect ratio : 6.95 inch wide/16:9
(effective display area:167mm x 93
Pixels : 112320 (480 x 234)
Color system : NTSC/PAL compalible
Operation temperature range : -30˚C to +85˚C
AUDIO
Maximum power output : 50W x 4
Preout output level(max) : 2 0V
Equalizer : OFF(normal), CLASSIC, POP, ROCK, JAZZ
BASS : Gain(-10dB to +10dB)
TREBLE : Gain(-10dB to +10dB)
Loudness : OFF, ON(+3.75dB)
Subwoofer : Gain(-79dB to 0dB)
Center : Gain(-79dB to 0dB)
FM RADIO
FM frequency range : 87.9MHZ to 107.9MHz
Signal to Nose rate : 60dB ↑( 75K MOD, 1KHz)
Usable senstivity : 10dBv ( 75K MOD, 1KHz)
Distor ion : 0 5% ↓ (22.5KHz MOD, 1KHz , 60dB)
Stereo Separation : 35dB ↑ ( 60dB, 1KHz)
AM RADIO
AM frequency range : 531KHz to 1710KHz
Usable senstivity : 20dBv ( 30K MOD, 400Hz)
Signal to Nose rate : 45dB ↑( 30K MOD, 400Hz)
