System Overview
1
SpaceStation, 2.0 gb 1- 3
Four tube guides are clipped in on the left and right housing side.
A pole clamp guide for attachment and locking of the pole clamp
is located at the housing back panel.
Abb.: 1 - 3 SpaceStation without SpaceCom, rear view
Legende zu Abb. 1 - 3:
ItemDesignation
1 Pole clamp guide
2 Release button
3 Connector “F3“
4 Connector “F4“
5 Connector “F1A“ (power input)
1
2
5 4 3
2.0
