System Overview
1
1- 4 SpaceStation, 2.0 gb
SpaceStation with SpaceCom
The physical construction of the SpaceStation front side with
SpaceCom corresponds exactly to the physical construction of the
SpaceStation without SpaceCom. The only visible difference is to
be found on the right side and the rear side.
Interfaces and a status- and alarm LED are located on the right-
hand side behind the connector cover and the W-LAN cover. A
battery module can be inserted in the battery compartment on
the rear side. The opening is covered by the battery compartment
cover.
A fan grid with fan is fitted on the left side of the battery com-
partment.
Abb.: 1 - 4 SpaceStation with SpaceCom, rear view
Legende zu Abb. 1 - 4:
ItemDesignation
1 Fan grid
2 Battery compartment with battery compartment cover
3 Connector cover
4 W-LAN cover for W-LAN- module
1 2
4
3
