BRINTER ONE User Manual

46
10. Printout job status – Details of the print job, i.e., the progress of the print job, name of the
print job, print speed, estimated printing time, layer height, and the current layer, are shown
when the printing process is ongoing.
11. Printout – The CAD model of the object being printed.
12. Z tip tuning – Use the up and down arrows to fine-tune the distance of the needle from the
print surface during printing.
13. Feed % – Change the material feed factor between 50–300% during printing. The default is
set to 100%. Available only for screw-fed print heads.
14. Speed % – Change the print speed during printing by a factor of 20–300%. The default is set
to 100%.
15. Tool pressure – Adjust the print head extrusion pressure during printing. Click the save icon
to store the new pressure setting into the material profile.
16. Syringe heater temperature – Adjust the syringe barrel temperature during printing. Click the
save icon to store the new temperature setting into the material profile. Available only for
print heads with a heater or cooler.
17. UV light – Turn on the print head integrated LEDs for manual curing.
18. Pause – Click to pause the print job.
10
11
15
16
17
18
12
13
14

BRINTER ONE Specifications

General

Brand	BRINTER
Model	ONE
Category	3D Printers
Language	English
