BRINTER ONE - Automatic Calibration of Multiple Print Heads

42
3.4.7.3 Automatic Calibration of Multiple Print Heads
The automatic calibration of the XYZ-offsets between various print heads is done with the help of the
light gate located at the front part of Brinter
®
’s frame. Only XY offsets are auto-calibrated by default,
but if auto-calibration of the Z axis is also wanted, this has to be enabled from the Settings menu
first. Note that Granu Tool cannot be automatically calibrated in the light gate.
11. Settings – Menu for Brinter-specific settings.
12. Switch for turning on the automatic calibration of the Z axis with the light gate.
13. Auto XYZ Calibration – Perform the automatic calibration of the needle with the light gate.
14. Clear Calibration –Reset the previously saved XYZ positions.
11
12
13
14
