BRINTER ONE - Page 74

74
Reassemble the tool by following the disassembly procedure in reverse order.
Push the bearing into its place from underneath [8].
Put the lower fastener of the extruder screw into its place and push the extruder into its place through
the fastener while putting the belt back on both pulleys [9]. Tighten the screw of the lower fastener.
Put the from cover into its place and screw it on [4].
Put the upper cover carefully in its place [3] and screw it on [2]. Put the hopper in its place and screw
it on.
6
7
8
9
