Brother DCP-L5652DN Service Manual

2-79
Confidential
 Error code C700
There is insufficient memory to expand PC print data.
 Error code C800
The memory size allotted for Secure Print was exceeded when saving Secure Print data.
 Error code D100
An error occurred while initializing the modem.
 Error code D200
Detected that the modem PCB is not connected.
 Error code D800
An error occurred while initializing the touch panel.
<User Check>
• Print the print data stored in the memory.
• Divide the print data and print them separately.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Print the print data stored in the memory.
• Divide the print data and print them separately.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the
modem flat cable
Reconnect the modem flat cable.
2 Modem PCB failure Replace the modem PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Modem PCB failure Replace the modem PCB ASSY.
2 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Panel firmware version and
main firmware version do not
match
Install the latest main firmware.
2
Connection failure of the panel
flat cable
Reconnect the panel flat cable.
3 LCD relay PCB failure Replace the LCD panel ASSY.
4 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
