Brother MFC-J2320 Service Manual

Confidential
2-74

Stained leading edge of recording paper
 Overlapping lines over the whole page
User Check
- Check whether the recording paper being used is within
the specification.
Step Cause Solution
1 Maintenance unit stained Clean the maintenance unit (refer to Section
4.3.2 in this Chapter.)
2 Paper feeding correction value
not updated
Adjust the paper feeding correction value (refer
to Chapter 5, Section 1.3.19.)
3 Head defective Replace the head/carriage unit.
User Check
- Carry out head cleaning.
Step Cause Solution
1 Head inclination is not correctly
adjusted.
Adjust the head inclination (refer to Chapter 4,
Section 2.4.)
2 Head calibration uncompleted Input the head calibration data (refer to Chapter
5, Section 1.3.2.)
3 Paper feeding correction value
not updated
Adjust the paper feeding correction value (refer
to Chapter 5, Section 1.3.19.)
4 PF encoder disk stained Clean the PF encoder disk and flushing guide
(refer to Chapter 3, Section 1.)
5 PF encoder disk defective Replace the PF encoder disk.
6 Head defective Replace the head/carriage unit.
7 Main PCB defective Replace the main PCB ASSY.

Brother MFC-J2320 Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi
Max Print Resolution	6000 x 1200 dpi
Max Print Size	A3
Scanner Type	Flatbed with ADF
Max Scan Resolution	1200 x 2400 dpi
Copy Speed (Black)	12 cpm
Copy Speed (Color)	9 cpm
Paper Tray Capacity	250 sheets
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Display	2.7" LCD touchscreen
Paper Handling	A3, A4
