Brother MFC-J2320 Service Manual

Confidential
2-75

Separated lines over the whole page
 Overlapping lines at the trailing edge of the recording paper
User Check
- Carry out head cleaning.
Step Cause Solution
1 Head inclination is not correctly
adjusted.
Adjust the head inclination (refer to Chapter 4,
Section 2.4.)
2 Head calibration uncompleted Input the head calibration data (refer to Chapter
5, Section 1.3.2.)
3 Paper feeding correction value
not updated
Adjust the paper feeding correction value (refer
to Chapter 5, Section 1.3.19.)
4 PF encoder disk stained Clean the PF encoder disk and flushing guide
(refer to Chapter 3, Section 1.)
5 Non-discharge of ink from
head
Carry out the recommended purge procedures
(refer to the recommended procedures in
Chapter 5, Section 1.3.29 "Purge Operation
(Maintenance mode 76)".)
6 PF encoder disk defective Replace the PF encoder disk.
7 Head defective Replace the head/carriage unit.
8 Main PCB defective Replace the main PCB ASSY.
User Check
- Carry out head cleaning.
Step Cause Solution
1 Paper feeding correction value
not updated
Adjust the paper feeding correction value (refer
to Chapter 5, Section 1.3.19.)
2 PF encoder disk stained Clean the PF encoder disk and flushing guide
(refer to Chapter 3, Section 1.)
3 PF encoder disk defective Replace the PF encoder disk.
4 Main PCB defective Replace the main PCB ASSY.
