3-99
Confidential
Assembling Note: When attaching the Paper feed motor gasket, align it in the position
indicated below.
Fig. 3-112
Paper feed motorPaper feed motor gasket
Paper feed motor gasket
within 2 mm
within 2 mm
Paper feed motor
(Upside)
(Side)
