Brother MFC-J2320 Service Manual

Confidential
2-49
Document
scanner sensor detects that document scanner is open.
User Check
- Close the document scanner.
First side document scanning position sensor detects length of document 90 cm or
more.
User Check
- Check whether the document scanned is longer than the specified limit.
- Remove the jammed document.

Error Code A1
Cover is Open
LCD
Step Cause Solution
1 Sensor relay PCB harness
connection failure
Reconnect the sensor relay PCB harness.
2 Document scanner sensor
defective
Replace the sensor relay PCB ASSY.
3 Document scanner unit boss
broken
Replace the document scanner unit.
4 Main PCB defective Replace the main PCB ASSY.

Error Code A2
Document Jam
LCD
Step Cause Solution
1 First side document scanning
position actuator caught on the
surrounding parts
Set the first side document scanning position
actuator into place.
2 First side document scanning
position sensor defective
Replace the first side document scanning
position sensor PCB.
3 ADF motor defective
Document feed roller worn out
Replace the ADF unit.
4 Sensor relay PCB defective Replace sensor relay PCB.
5 Main PCB defective Replace the main PCB ASSY.
