3-19
Confidential
3 Scanner harness holder
<A view>
A view
FB motor harness
ADF motor harness
ADF sensor harness
Cable guide
Flat core
FFC separator
Cable guide
Cable guide
Second side
First side CIS flat cable
Document MP
sensor harness unit
First side CIS flat cable
Flat core
FFC separator
Flat core
Second side CIS flat cable
Upper cover
FB FG wire
CIS flat cable
FB document size sensor harness
