3-20
Confidential
4 ADF unit/Document scanner unit
ADF unit
Document
scanner unit
ADF motor harness
ADF sensor harness
First side
FB motor harness
Document MP sensor harness unit
Second side CIS flat cable
MP sensor harness ASSY
Document cover
sensor
CIS flat cable
ADF FG wire
FB FG wire
Ferrite core
