3-21
Confidential
5 Head/carriage unit
6 Paper feed arm frame ASSY
Cable guide
Boss
Cable guide
Carriage flat cable
Cable guide
Cable guide
Cable guide
Paper feed arm frame ASSY
Paper feed arm frame harness
Registration sensor harness
Flushing box
Inner chute ASSY
