3-22
Confidential
7 Lower cover L
8 Ink cartridge cover sensor
Cable guide
Cable guide
Switchback sensor harness
Registration sensor harness
Cable guide
Cable guide
PF motor
harness
Lower cover
Cable guide
T2 detection sensor harness
T2 FG
PF FG wire
PF encoder
sensor harness
T1 paper remaining sensor harness
T1 detection
sensor harness
T2 paper remaining sensor harness
wire
3rd tray relay harness
3rd tray paper feed
motor harness
Cable guide
Cable guide
Lower cover
Ink cartridge cover sensor harness
Ink cartridge
cover sensor
