3-26
Confidential
15 Registration sensor harness
16 Ink refill ASSY
Inner chute ASSY
Cable guide
DX paper guide
Registration sensor harness
Registration sensor PCB
Frame CR unit
Cable guide
Cable guide
Carriage motor harness
Ink refill ASSY
Lower cover
ASF motor harness
Cable guide
Carriage motor harness
ASF motor harness
< Ink tank model >
Cable guide
Cable guide
Cable guide
Ink supply tubes
Ink supply tubes
Ink supply tubes
< Simple Ink cartridge model >
