3-27
Confidential
17 Upper cover
18 3rd tray relay PCB
Cable guide
Cable guide
Cable guide
Cable guide
Upper cover
Document scanner sensor harness
Cable guide
Cable guide
Cable guide
Cable
guide
Ferrite
core
Cable guide
3rd tray paper feed
motor harness
3rd tray paper feed
motor harness (White)
Cable guide
T3 paper remaining sensor harness
3rd tray relay PCB
3rd tray paper pull-in
3rd tray relay harness
sensor harness
T3 detection sensor harness
(Green & Black)
