Bruker HPPR/2 User Manual

Cover2 Module
H172204_1_001 39 / 92
6.2.1 Rear Side Connectors
NOTICE
Material damage hazard
Never plug in anything else other than the below mentioned connected devices to any of the
RJ-45 connectors on the Cover2 rear side.
Case Label Connector
Type
Description
RF-OUT BNC Not used for AVANCE NEO.
LOCK-OUT BNC Not used for AVANCE NEO.
TUNING-IN BNC Not used for AVANCE NEO.
HPPR CONTROL D-Sub 37 Control signals (BFB, real time pulses, emergency stop)
and power supply for preamplifier modules, QNP, ADM,
ADM-CRP.
CRP/ATMA/PICS/
HWIDS
RJ-45 Socket number 9 ... 10: - Connection either to CRP, ATMA,
PICS or HWIDS.
HWIDS RJ-45 Socket number 1 ... 8: - Connection to HWIDS only.
Table6.5: Connectors on the rear side
NOTICE
Cover2 damage hazard
To connect the CRP / ATMA / PICS / HWIDS devices use exclusively the following cable:
Connected Device Cable (Material Number)
CRP Z14362
ATMA Z14361
PICS Z14361
HWIDS H135248
Table6.6: Appropriate Cable for Connected Devices
