16 Technical Data
The HPPR/2 System consists of a stack of several subunits (modules) with one cover module
on top. This section contains only general data of the modules. For RF-performance data of a
specific module please refer to the section Technical Specifications [}48].
16.1 General Information
Data Value Unit
Cover module Weight 2 kg
Height 110 mm
Preamp module
a
Weight 2..3 kg
Height 40..55 mm
All modules Length 350 mm
Width 270 mm
a
Depending on module type.
Table16.1: Technical Data: General Information
16.2 Connection Values
All HPPR/2 modules are supplied with dc voltages from the spectrometer console. There is
no mains connection.
Standard Preamp modules are supplied via the Cover module. HPLNA an ADM-modules
have an additional power supply connected directly to the console.
Electrical
Data Value Unit
Cover module Voltages + 9
+ 19
- 19
Vdc
Vdc
Vdc
power consumption, maximum 4 W
Preamp module
standard supply
Voltages from Cover module
power consumption, maximum
a
4..20 W
HPLNA module
additional supply
Voltages + 500
- 5
± 20
Vdc
Vdc
Vdc
power consumption, maximum 23 W
ADM module
additional supply
Voltages + 7.5
± 19
- 36
Vdc
Vdc
Vdc
