Bruker HPPR/2 User Manual

HPPR/2 Preamplifier Modules for AVANCE NEO
H172204_1_001 51 / 92
7.5.7 Technical Data HPPR/2 2H MODULE (ECL>=07)
300 - 900 950 - 1000
Receive Path Performance
Gain (typ) 28 dB (42 dB in Lock Mode) 28 dB (42 dB in Lock Mode)
Noise Figure (typ) 1.3 dB 1.2 dB
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
Insertion Loss ≤ 1.6 dB ≤1.6 dB
Table7.10: Technical Data HPPR/2 2H Module
7.5.8 Technical Data HPPR/2 15N MODULE (ECL>=07)
400 - 600 700 - 900 950-1000
Receive Path Performance
Gain (typ) 28 dB 28 dB 28 dB
Noise Figure (typ) 1.5 dB 1.2 dB 1.3 dB
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
Insertion Loss ≤ 1.6 dB ≤ 1.0 dB ≤ 1.0 dB
Table7.11: Technical Data HPPR/2 15N Module
