7.5.2 Technical Data AQS XBB19F 2HS MODULE (ECL>=07)
300 - 400
Receive Path Performance
Gain (typ) 28 dB
Noise Figure 13C (typ) 1.2 dB
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
Insertion Loss 13C ≤ 0.7 dB
Table7.5: Technical Data AQS XBB19F 2HS Preamp
7.5.3 Technical Data HPPR/2 1H HPLNA MODULE (19F-1H)
200 - 600 650- 900 950 - 1000
Receive Path Performance
Gain (typ) 28 dB 28 dB 28 dB
Noise Figure 1H (typ) 0.9 dB 1.0 dB 1.1 dB
1dB Compression Point ≥ -12 dBm
(Input Power)
≥ -12 dBm
(Input Power)
≥ -12 dBm
(Input Power)
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 4 kW (0.1 ms)
4 kW (1 ms)
4 kW (10 ms)
4 kW (0.1ms)
4 kW (1 ms)
4 kW (10 ms)
4 kW (0.1 ms)
4 kW (1 ms)
4 kW (10 ms)
Insertion Loss 1H ≤ 0.9 dB ≤ 0.9 dB ≤ 0.9 dB
Table7.6: Technical Data HPPR/2 1H HPLNA Module
