Bruker HPPR/2 User Manual

HPPR/2 Preamplifier Modules for AVANCE NEO
50 / 92 H172204_1_001
7.5.4 Technical Data HPPR/2 3H HPLNA MODULE
300 - 600 700 - 800
Receive Path Performance
Gain (typ) 28 dB 28 dB
Noise Figure (typ) 0.9 dB 1.0 dB
1 dB Compression Point ≥ -12 dBm
(Input Power)
≥ -12 dBm
(Input Power)
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 4 kW (0.1 ms)
4 kW (1 ms)
4 kW (10 ms)
4k W (0.1 ms)
4 kW (1 ms)
4 kW (10 ms)
Insertion Loss ≤ 0.9 dB ≤ 0.9 dB
Table7.7: Technical Data HPPR/2 3H HPLNA Module
7.5.5 Technical Data HPPR/2 31P MODULE (ECL>=07)
400 - 1000
Receive Path Performance
Gain (typ) 28 dB
Noise Figure (typ) 1.5 dB
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 500 W (0.1 ms)
400 W (1 ms)
300 W(10 ms)
Insertion Loss ≤ 1.6 dB
Table7.8: Technical Data HPPR/2 31P Module
7.5.6 Technical Data HPPR/2 13C MODULE (ECL>=08, 79Br-13C)
400 - 900 950 - 1000
Receive Path Performance
Gain (typ) 28 dB 28 dB
Noise Figure 13C (typ) 1.5 dB 1.6 dB
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
Insertion Loss 13C ≤ 1.6 dB ≤ 1.6 dB
Table7.9: Technical Data HPPR/2 13C Module
