Bruker HPPR/2 User Manual

MRI Active Detuning Module
62 / 92 H172204_1_001
10.2.5 Connectors
Position Label Connector Type Description
PROBE CHANNEL MDR (mini-delta
ribbon female)
Detuning output signals to coil connector
RF IN SMA (coax female) RF input signal from coil or array preamp
TRANSM RF OUT N (coax female) RF output signal to AQS RXAD
CONSOLE UT0 19pol.
(multiple coax and
DC contacts)
Receiver gating pulses from AQS RXAD
Blanking pulses and tuning signals from AQS
PSD
Power supply from AQS PSM ADM
PREAMP RF IN
RF OUT
EXT_RGP~
TUNE
SMB (coax male) RF input from preamplifier module
RF output to preamplifier module
Receiver gating pulse output to preamplifier
module
Tuning signal output to preamplifier module
Table10.1: Connector Description
10.2.6 Part Numbers
Bruker Part No. Description
Z107408 HPPR/2 MRI ACTIVE DETUNING MODULE
Table10.2: Part Number: ADM
