HPPR/2
26 / 92 H172204_1_001
5.3.1 FAQs
Which HPPR/2 modules are equipped with a power limit detection?
As of January 2008, the following modules are equipped with a power limit detection:
• Z003950 AQS 1H2H PREAMP 300
• Z128274 AQS 1H2H PREAMP 400 CRP
• All frequencies HPPR/2 1H HPLNA MODULE
Additional modules will be published by EC only.
How can I see if the supervision is activated?
Cover2: The supervision can be disabled via the Hosted Devices | Cover2 Overview |
Module Settings | Overload Detect website. After power up the supervision is always
enabled automatically (default).
What happens in case of missing power entries in the PICS?
If a value is missing in the $PChan group of the PICS, the maximum power rating of the
corresponding HPPR/2 module will be set.
What happens in case of „incorrect“ or „corrupt“ (non numerical) power entries of the probe
PICS?
The maximum power rating of the corresponding HPPR/2 module will be set.
What happens in case of higher rating of the probe than the HPPR/2 module?
The maximum power rating of the corresponding HPPR/2 module will be set.
What happens if the probe contains no PICS?
All limits of the HPPR/2 modules will be set to its corresponding maximum power ratings.
How can I check whether the supervision is available for a certain HPPR/2 module?
Check on the HPPR/2 COVER2 display as described in HPPR/2 RF Power Supervision
[}24].
How can I check whether the supervision is available for a certain nucleus by using the AQS
integrated preamplifiers?
Check the $HpprFunc group of the module BIS. The version of the group must be at least 2.3
and the sixth entry must be set to 1.
The $HpprFunc group is valid for all HPPR/2 modules and not only for the AQS integrated
preamplifiers.
