Bruker HPPR/2 User Manual

HPPR/2 Baseplate AV4
56 / 92 H172204_1_001
8.2 Description
The standard baseplates have BNC connectors for RF-OUT and LOCK-OUT signals to the
TRANSCEIVER (TRX) in the AQS chassis of the console. The TUNE and RGP-HPPR
signals from the TRX and PSM-A are bundled in cables (4 channels each) and linked via d-
sub connectors to the baseplate. Inside the baseplate some RGPs are split with resistive
splitters. All cables to the preamplifiers have SMB connectors.
The MAS3 baseplate is functionally the same as the 8CH baseplate. But because it is
mounted on top of the MAS3 UNIT it has a standard preamplifier housing.
8.2.1 Part Numbers
Bruker Part No. Description
Z155568 HPPR/2 BASEPLATE AV4 4CH
Z155569 HPPR/2 BASEPLATE AV4 8CH
Z165937 HPPR/2 MAS3 BASEPLATE AV4 8CH
Table8.1: Part Numbers: BASEPLATE AV4
8.2.2 Technical Data
Frequency range
- all RF signals 0.005 .. 1.5 GHz
Insertion loss @ 1 GHz
- RF-IN, RF-OUT, LOCK-OUT:
(BNC > SMB)
0.3 dB (connector) + 1.0 dB/m
- TUNE IN: (D-SUB > SMB) 0.5 dB (connector) + 1.7 dB/m
RGP splitter
Resistive 2 or 3-way splitter, 1
resistor per output
330 Ω
8.3 Troubleshooting
The BASEPLATE can only be replaced as a whole unit (FEU). There are no serviceable
parts.
If an FRU needs to be replaced, contact your Bruker Service Representative.
