Bruker HPPR/2 User Manual

HPPR/2 MRI ADM-CRP Module
H172204_1_001 67 / 92
11.2.3 Connectors
Position Label Connector Type Description
PROBE TMD D-SUB
(delta ribbon)
TMD output signals to MRI cryo probe.
WOBBLE CH 1-4 SMA
(coax female)
Wobble signal to/from MRI cryo probe.
TRANSM ADM IN UT0 19pol
(multiple coax
and dc contacts)
Control pulses from MRI AD-CTRL board,
Power supply from AQS PSM ADM.
ADM OUT
PREAMP RF IN SMB
(coax male)
RF input from other HPPR/2 modules.
RF OUT RF output to AV4 TRX (AQS)
a
.
TUNING IN TUNE input from AV4 TRX (AQS)
a
.
TUNING OUT TUNE output to other HPPR/2 modules.
MODULE
CONTROL
D-SUB
(delta ribbon)
I2C interface, control pulses, power supply
from HPPR/2 COVER2.
a
Via HPPR/2 MRI BASEPLATE
Table11.2: Connector Description
11.2.4 Part Numbers
Bruker Part No. Description
Z130507 HPPR/2 MRI ADM-CRP MODULE 200-400
Z130508 HPPR/2 MRI ADM-CRP MODULE 500-750
Table11.3: Part Numbers: ADM-CRP
