HPPR/2 Preamplifier Modules for AVANCE NEO
52 / 92 H172204_1_001
7.5.9 Technical Data HPPR/2 XBB19F 2HP MODULE (ECL>=07)
300 - 700
Receive Path Performance
Gain (typ) 28 dB
Noise Figure 13C (typ) 1.0 dB
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 500 W (0.1 ms)
400 W (1 ms)
300 W (10 ms)
Insertion Loss 13C ≤ 0.7 dB
Table7.12: Technical Data HPPR/2 XBB19F 2HP Module
7.5.10 Technical Data HPPR/2 XBB31P 2HP HPLNA MODULE
200 - 600 650- 1000
Receive Path Performance
Gain (typ) 28 dB 28 dB
Noise Figure 13C (typ) 1.0 dB 1.1 dB
1dB Compression Point ≥ -11 dBm (Input Power) ≥ -11 dBm (Input Power)
Transmit Path Performance
Max. Power Rating, 2% Duty Cycle 2 kW (0.1 ms)
700 W (1 ms)
550 W (10 ms)
2 kW (0.1 ms)
700 W (1 ms)
550 W (10 ms)
Insertion Loss 13C ≤ 0.6 dB ≤ 0.6 dB
Table7.13: Technical Data HPPR/2 XBB31P 2HP HPLNA Module
