Bruker HPPR/2 User Manual

HPPR/2 MRI ADM-CRP Module
H172204_1_001 65 / 92
11 HPPR/2 MRI ADM-CRP Module
11.1 Overview
The HPPR/2 MRI ADM-CRP MODULE 200-400 (ADM-CRP) belongs to the group of MRI
interface modules. It has similar functions as the HPPR/2 MRI ACTIVE DETUNING MODULE
(ADM) but is exclusively used for 1H MRI array cryo probe (RX only).
In addition to the ADM, the ADM-CRP contains a preamplifier with four channel tuning
(wobble) capability. There are two frequency versions; 200-400 MHz and 500-750 MHz.
Figure11.1: View HPPR/2 MRI ADM-CRP Module
11.2 Description
Figure11.2: Block Diagram: MRI ADM-CRP Module
