BWT Perla - 17 Technical Data; 17.1 Dimensions

74
EN
17.1 Dimensions
Designation BWT Perla BWT Perla seta
Height A mm 797
Width B mm 394
Depth C mm 505
Water inlet connection height D mm 592
Water outlet connection height E mm 652
 F mm 410
Clearance to allow the technology cover to
be opened
G mm 400
Min. sewage system connection DN 40
B
D
A
C
E
F
G
