CHAPTER 2 BASIC OPERATION PROVIDES
• Outputs from the DC Controller (4/5)
Figure 2-115
DC controller PCB
FM15
Reader cooling fan 1
Reader cooling fan 2
Drum cartridge
cooling fan 1
DC controller PCB
cooling fan
Scanner motor
cooling fan
FM12
J104-B5
-B6
-B7
J55
FM13
J107-B8
-B9
-B10
J56
FM14
J119-1
-2
-3
J58
J119-4
-5
-6
J60
J437
FM16
J119-7
-8
-9
J67
FM17
J112-B10
-B11
-B12
J47
J428
J104-A11
-A12
-A13
J54
J436
FM12D
FM12LCK
FM13D
FM13LCK
FM14D
FM14LCK
FM15D
FM15LCK
FM16D
FM16LCK
FM17D
FM17LCK
FM18D
FM18LCK
Drum cartridge
cooling fan 2
Drum cartridge
cooling fan 3
FM18
While the fan is rotating, FM18D is '1'.
While rotating at a specific speed,
returns the CLK signal to the PCB.
While the fan is rotating, FM16D is '1'.
While rotating at a specific speed,
returns the CLK signal to the PCB.
While the fan is rotating, FM17D is '1'.
While rotating at a specific speed,
returns the CLK signal to the PCB.
While the fan is rotating, FM15D is '1'.
While rotating at a specific speed,
returns the CLK signal to the PCB.
While the fan is rotating, FM14D is '1'.
While rotating at a specific speed,
returns the CLK signal to the PCB.
While the fan is rotating, FM13D is '1'.
While rotating at a specific speed,
returns the CLK signal to the PCB.
While the fan is rotating, FM12D is '1'.
While rotating at a specific speed,
returns the CLK signal to the PCB.
