Printer parts
h. OK button
Press this button on the T ab Selection screen to display the menu of the tab shown.
Pressing this button in menu items of each tab for which is displayed at left will move to the lower
level of the menu item, enabling you to execute menu commands or set menu values.
Also press this button if the Display Screen indicates to press the OK button.
i. Back button
Displays the screen before the current screen.
j. Menu button
Displays the T ab Selection screen . ( → P .49)
k. Load button
Press this button when loading or replacing paper .
( → P .106)
( → P .136)
l. Feed button
Pressing this button when rolls are loaded enables you to reposition the paper . ( → P .125)
m. Cut button
Pressing this button when rolls are loaded cuts the paper , if you have specied Automatic or Eject
in Cutting Mode in the Control Panel menu. ( → P .129)
n. Cut Sheet lamp (green)
Lit when sheets are selected as the paper source.
o. Roll Media lamp (green)
Lit when rolls are selected as the paper source.
Note
• T o recover from Sleep mode, any button can be pressed except the Power button.
Printer Parts 21
