Canon imagePROGRAF iPF750 User Manual

HP-GL/2 problems
HP-GL/2 problems
W ith HP-GL/2, printing is misaligned
Cause Corrective Action
The plotter origin is incorrect. Check the printing commands.
The Margin setting in the Control Panel menu is
incorrect.
Adjust the Margin setting values in the Control Panel
menu.
Lines or images are missing in printed HP-GL/2 jobs.
Cause Corrective Action
The memory is full. Check the size of the data in the print job.
An HP-GL/2 command not supported by this printer
was received.
Check the print job and settings.
The printer has received print data that includes HP
R TL commands when Auto Rotate is On in the
Control Panel menu.
In the Control Panel , set Auto Rotate to Off and
print again.
( → P .49)
Lines are printed too thick or thin in HP-GL/2 print jobs
Cause Corrective Action
The W idth setting in the Control Panel menu is
incorrect.
Check the W idth setting value specied for Pen
no. in Palette A or Palette B in the Control
Panel menu. If ne lines are printed faintly , setting
ThickenFineLines to On will print the lines more
distinctly .
( → P .49)
HP-GL/2 jobs are printed in monochrome (or color)
Cause Corrective Action
The Color Mode setting in the Control Panel menu
is incorrect.
Check the Color Mode setting in the Control Panel
menu.
( → P .49)
However , for optimal Printhead performance, the
printer consumes trace amounts of color ink even
when Monochrome is selected as Color Mode .
Printed colors of lines are inaccurate during HP-GL/2
printing
Cause Corrective Action
AdjustFaintLines is On in the Control Panel menu. Setting AdjustFaintLines to Off in the Control
Panel menu may help produce the expected results.
However , lines in some colors may appear broken.
682 T roubleshooting

Canon imagePROGRAF iPF750 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	75000 g
Bundled software	Canon Printer Driver, Digital Photo Front-Access, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), HDI Driver for AutoCAD4, PosterArtist Lite (PC Only), Print Plug-in for Microsoft Word/Excel/PowerPoint (PC only)
Media thickness	0.07 - 0.8 mm
Roll top margin	18000 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media types supported	10\
ISO A-series sizes (A0...A9)	A0, A1, A2
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	U L (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB
Built-in processor	L-COA
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP (IPv4/IPv6), IPX/SPX, AppleTalk, SNMP (Canon MIB supported), HTTP
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	1 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 (32/64bit), Macintosh OSX 10.3.9-10.6 (32 bit), OS X 10.5-10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1304 x 870 x 1062 mm
