Network Setting (Windows)
Specifying the Printer s Frame T ype
T o enable communication between the printer and computers on your network, specify the Ethernet frame
type in your NetW are environment.
Follow these steps to specify the frame type by using imagePROGRAF Device Setup Utility or the printer
Control Panel .
Note
Y ou can specify the frame type by using RemoteUI if the printer s IP address is congured.
Important
Before specifying the frame type, make sure the printer is on and connected to the network.
For instructions on installing imagePROGRAF Device Setup Utility , see “Installing imagePROGRAF
Device Setup Utility”. (→P .452)
Specifying the frame type using imagePROGRAF Device Setup Utility
1. Start imagePROGRAF Device Setup Utility .
2. In the list of printers, select the printer to congure.
3. Choose Protocol Settings from the Printer menu.
4. Click the NetW are tab and select the frame type in the NetW are Frame T ype list.
5. Click the IPv4 tab and select ETHERNET II in the Frame T ype list.
6. In IP Address , enter the IP address assigned to the printer , and then enter the subnet mask in
Subnet Mask and the default gateway in Gateway Address .
Important
Y ou must specify the IP address here to be able to congure NetW are protocol settings using
RemoteUI .
7. Click Set .
8. Click OK after the Conrmation message is displayed.
9. Exit imagePROGRAF Device Setup Utility .
586 Network Setting
