Canon imagePROGRAF iPF750 User Manual

Free Layout
Changing the Object Size
Y ou can change the object size by means of mouse operation or by specifying a scaling value.
Note
• The vertical-to-horizontal ratio remains unchanged when the object is enlarged or reduced.
Resizing by means of mouse operation
1. Select an object.
2. Place the pointer at a corner of the selection box around the object to show the arrow handle,
and drag this handle to change the object size.
Resizing by specifying a scaling value
1. Select an object.
Click on the “Enl./Red.” checkbox in the Format Dialog Box (→P .399) and select “Scaling” .
2. Y ou either enter numbers directly .
Note
• Y ou can input between 25 and 600.
• Y ou can change the numbers by clicking either “▲” button or “▼” button.
3. Click the “OK” button.
408 Windows Software

Canon imagePROGRAF iPF750 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	75000 g
Bundled software	Canon Printer Driver, Digital Photo Front-Access, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), HDI Driver for AutoCAD4, PosterArtist Lite (PC Only), Print Plug-in for Microsoft Word/Excel/PowerPoint (PC only)
Media thickness	0.07 - 0.8 mm
Roll top margin	18000 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media types supported	10\
ISO A-series sizes (A0...A9)	A0, A1, A2
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	U L (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB
Built-in processor	L-COA
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP (IPv4/IPv6), IPX/SPX, AppleTalk, SNMP (Canon MIB supported), HTTP
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	1 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 (32/64bit), Macintosh OSX 10.3.9-10.6 (32 bit), OS X 10.5-10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1304 x 870 x 1062 mm
