Canon imagePROGRAF iPF750 User Manual

Network Setting (Mac OS X)
Conguring the Printer ’ s AppleT alk Network Settings
Follow the steps below to congure the AppleT alk network settings.
1. Start the web browser and enter the following URL in the Location (or Address ) box to display
the RemoteUI page.
http:// “printer IP address or name” /
Example: http://xxx.xxx.xxx.xxx/
2. Select Administrator Mode and click Logon .
3. If a password has been set on the printer , enter the password.
4. Click Network in the Device Manager menu at left to display the Network page.
5. Click Edit in the upper-right corner of the AppleT alk group to display the Edit AppleT alk
Protocol Settings page.
6. Refer to the AppleT alk Settings Items table to complete the settings.
AppleT alk Settings Items
Item Details
Default Setting
Phase T ype Specify whether to use AppleT alk.
If you will use AppleT alk, choose
Phase 2 .
If you will not use AppleT alk,
choose Disabled .
Disabled
Name (*1) Specify the object name used by
AppleT alk (in up to 31 single-byte
or 15 double-byte characters).
However , do not use the following
single-byte characters: @, *, :,
and =.
Canon NB-18GB (xxxxxx)
Zone (*2) Specify the printer zone name, up
to 31 single-byte characters.
However , do not use the following
single-byte characters: Also avoid
using “*” (which represents the
default zone) in the middle of a
string.
*
*1: The object name you have specied in Name is displayed in Printer Setup Utility (or Print Center )
in Mac OS X 10.2.8-10.4. If you use multiple printers in the same zone, assign a unique name to
each printer . By default, the network interface name is “Canon NB-18GB (xxxxxx).” (Here, xxxxxx is
the last six digits of the printer ’ s MAC address.)
*2: If zones have been created on the network, enter the name of the printer ’ s zone. If there are
no zones, leave the asterisk “*” entry (for the default zone) as it is. If you enter a network zone
name that does not match created zones, the printer will not be detected by Macintosh computers.
Consult your network administrator for information on zone names.
7. Click OK to display the Network page.
Network Setting 597

Canon imagePROGRAF iPF750 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	75000 g
Bundled software	Canon Printer Driver, Digital Photo Front-Access, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), HDI Driver for AutoCAD4, PosterArtist Lite (PC Only), Print Plug-in for Microsoft Word/Excel/PowerPoint (PC only)
Media thickness	0.07 - 0.8 mm
Roll top margin	18000 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media types supported	10\
ISO A-series sizes (A0...A9)	A0, A1, A2
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	U L (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB
Built-in processor	L-COA
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP (IPv4/IPv6), IPX/SPX, AppleTalk, SNMP (Canon MIB supported), HTTP
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	1 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 (32/64bit), Macintosh OSX 10.3.9-10.6 (32 bit), OS X 10.5-10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1304 x 870 x 1062 mm
