Canon imagePROGRAF iPF750 User Manual

Adjusting the feed amount
Selecting a Feed Amount Adjustment Method (Feed
Priority)
Methods of adjusting the amount paper is fed are set in Adj. Priority .
Adjust Adj. Priority to suit your particular printing application.
• Print Quality : Adjusts the feed amount to reduce banding across the sheet in printed documents.
Adj. Quality settings are applied. When Adj. Fine Feed is executed, the Adj. Fine Feed settings are
applied in addition to the Adj. Quality settings.
• Print Length : Adjusts the feed amount for better accuracy of lines in printed documents.
The settings of A:High or B:Standard/Draft in Adjust Length are applied.
• Automatic : Print Quality or Print Length is selected, depending on Print Priority as selected in the
printer driver at the time of printing.
Image or Ofce Document : Print Quality is selected.
Line Drawing/T ext : Print Length is selected.
Note
• Either B:Standard/Draft or A:High in the Adjust Length menu is applied, depending on printer driver
settings at the time of printing.
• If you have selected Easy Settings in the printer driver , follow these steps to conrm the Print Priority
setting.
• Windows: Click V iew Settings on the Main tab to display the V iew Settings dialog box.
• Mac OS X: Click V iew set. on the Main pane to display the V iew settings dialog box.
Follow these steps to congure the settings.
1. Load the paper .
• Attaching the Roll Holder to Rolls (→P .103)
• Loading Rolls in the Printer (→P .106)
• Loading Sheets in the Printer (→P .136)
2. On the T ab Selection screen of the Control Panel , press ◄ or ► to select the Settings/Adj.
tab ( ).
Note
• If the T ab Selection screen is not displayed, press the Menu button.
3. Press the OK button.
The Set./Adj. Menu is displayed.
4. Press ▲ or ▼ to select Adjust Printer , and then press the OK button.
5. Press ▲ or ▼ to select Feed Priority , and then press the OK button.
6. Press ▲ or ▼ to select Adj. Priority , and then press the OK button.
7. Press ▲ or ▼ to select Automatic , Print Quality , or Print Length , and then press the OK
button.
Adjustments for Better Print Quality 613

Canon imagePROGRAF iPF750 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	75000 g
Bundled software	Canon Printer Driver, Digital Photo Front-Access, Printer Driver Extra Kit (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), HDI Driver for AutoCAD4, PosterArtist Lite (PC Only), Print Plug-in for Microsoft Word/Excel/PowerPoint (PC only)
Media thickness	0.07 - 0.8 mm
Roll top margin	18000 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media types supported	10\
ISO A-series sizes (A0...A9)	A0, A1, A2
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	U L (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB
Built-in processor	L-COA
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP (IPv4/IPv6), IPX/SPX, AppleTalk, SNMP (Canon MIB supported), HTTP
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Power consumption (PowerSave)	1 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 (32/64bit), Macintosh OSX 10.3.9-10.6 (32 bit), OS X 10.5-10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1304 x 870 x 1062 mm
