Note
z As soon as you select the name of a media size from
the Media Size List, the Width and Height settings of
the selected size are automatically entered.
z Select the Borderless Printing Size checkbox to
change the width display to the list of roll media lists
compatible with borderless printing. Select the
customized roll width using Width, and enter the
customized Height value.
z To fix the height/width ratio, select the Fix the Ratio of
the Width to Height checkbox. If the Height is
changed, the Width will change automatically
according to the previous height/width ratio. Similarly,
if the Width is changed, the Height will change
automatically.
Important
z The Fix the Ratio of the Width to Height is not
available when Borderless Printing Size is selected.
5 Click the OK button to close the dialog box.
Note
z You can define up to 50 custom sizes for media.
z The settings in the Media Size Options dialog box
remain in effect even after the software application is
closed.
z To delete a registered custom size, from the Media
Size List select the name of the custom size to delete,
then click the Delete button.
z To edit a registered custom size, from the Media Size
List, select the name of the custom size, then change
the Width and Height settings, then click the Add
button.
z The standard sizes (marked with a red dot “ ” on the
left), or sizes that you defined with another printer
driver (marked with a white dot “ ” on the left), can
be neither edited nor deleted.
