Canon LBP710Cx - Maintaining and Improving Print Quality

5
Remove the drum protective cover.
6
Install the toner cartridge.
● Align the toner cartridge with the toner cartridge guide ( ) and push it into the slot until it stops.
● Be careful that the drum portion does not get hit against the mouth of the slot.
● Place the toner cartridge into the slot marked with the appropriate color label ( ).
7
Close the front cover.
Maintenance
570
