The Settings editor
The Settings Editor
is a web-based application and therefore accessible via an Internet browser.
The Settings Editor enables you to manage settings or to display information in the following
areas.
• [Media]
• [Colour]
• [Preferences]
• [Workflow]
• [Transaction Printing (only with IPDS-license)]
• [Configuration]
• [Support]
Accessing the Settings Editor
Before using the Settings Editor make sure that you have the following information:
• The IP-address or hostname of the controller
• The Service- or Key Operator password. (675756 resp. 13524)
There are 2 ways to get access to the Settings Editor:
• Via a remote PC connected to the client network
• Via a laptop directly connected to the PRISMAsync controller
Access via client network
To get access to the Settings Editor do the following:
• Be sure the PC and the PRISMAsync are connected to the client network
• On the PC open an Internet browser (eg. Microsoft Explorer)
• In the address bar, enter the IP-address or the Hostname of the PRISMAsync. As a result the
Settings Editor will open. It is now possible to make changes in the above listed areas.
Access via direct connection to PRISMAsync
Sometimes you can not access the
Settings Editor via the client network. In this case it is better to
connect a PC/laptop directly to the PRISMAsync controller.
Follow these steps
Procedure
1.
Disconnect the cross-over Ethernet cable from the copier and connect it to the Ethernet port on
your laptop.
2.
Set the IP-address of your laptop to 134.188.254.21
3.
Set the Subnet mask of your laptop to 255.255.255.0
4.
On the laptop open an Internet browser (eg. Microsoft Explorer)
5.
In the address bar, enter http://134.188.254.11
6.
The Settings Editor will open in your Internet browser.
The Settings editor
58 Chapter 6 - The Settings Editor
PRISMAsync V3.2
