Firmware upgrade additional information
Additional information related to a firmware upgrade
Feedback:
The feedback shown combines the feedback of both the engine and PRISMAsync during the
firmware upgrade. The PRISMAsync (lines starting with PRISMAsync) will include information on
which files actually transferred to the engine and which files are skipped because of version is
present already or a module being non-present.
Version checking.
In order the system to operate correctly the engine and accessories and PRISMAsync must have
compatible firmware installed. Therefore version checking is executed by PRISMAsync controller.
•
Each PRISMAsync version will contain a list with compatible engine and accessories firmware.
• PRISMAsync will check if the installed engine and accessories firmware level matches with the
actual installed PRISMAsync version.
• Version checking is executed when starting a connection with the engine in normal user mode.
In (safe) download mode version checking is not executed.
• If non matching firmware is found PRISMAsync will report this in the data-log. The data log
information can be viewed in service mode -> error analysis.
Information on screen
Information on screen Explanation
1. Button to select
a. Auto upgrade
b. Non auto upgrade
2.
Button to start upgrade process.
3. Running process step
4. Detailed information by engine and or
PRISMAsync.
5. Via scroll bar text can be scrolled back.
PRISMAsync…….
PRISMAsync at beginning of a row:
Message generated by PRISMAsync.
Messages with e.g. DLM, EXT ….in front are
messages generated by engine.
4
Firmware upgrade additional information
92 Chapter 8 - Firmware upgrades via PRISMAsync
PRISMAsync V3.2
