Connect Harness 22W01

NOTE

When servicing components of the PRISMAsync always wear a grounded strap around your

wrist, to avoid electrostatic discharge that will harm your equipment.

Illustration

[23] Harness 22W01

Step Action

Be sure the AUX control board is mounted correctly in the PRISMAsync

•

[24] Connected AUX control board

Connect Harness 22W01

78 Chapter 7 - Service procedures

PRISMAsync V3.2
