Appendix
7
275
HTTP Port 80
HTTPS Port 443
•SNMP Server
SNMP Disable
Community Name public
Administrator Contact Information
Administration Function Name
VB-R11/VB-R11VE/
VB-R10VE
VB-M641VE/
VB-M641V/
VB-M640VE/VB-M640V
VB-M741LE/VB-M740E
Installation Location
• FTP Server
Use FTP Server Disable
• WS-Security
Check Time on Authentication Check
•Video Server
Maximum Number of Clients 30
Camera Control Queue Length 30
Maximum Connection Time (sec.) 0
Camera Control Time (sec.) 20
• Audio Server
Audio Transmission from the
Camera
Disable
Voice Activity Detection Disable
Audio Reception from Viewer Disable
• RTP Server
RTP Enable
RTSP Authentication Method Digest Authentication
RTSP Port 554
• Audio Multicast
Multicast Address 0.0.0.0
Multicast Port Number 0
Multicast TTL 1
• RTP Streaming 1
Video Size 320x180 JPEG
Frame Rate 5
Multicast Address 0.0.0.0
Multicast Port Number 0
Multicast TTL 1
Item Setting
R11 R10
M641 M640
M741 M740
R11
M641
M741
R11
M641
M741
Audio Transmission Disable
• RTP Streaming 2
Video Size 320x180 JPEG
Frame Rate 10
Multicast Address 0.0.0.0
Multicast Port Number 0
Multicast TTL 1
Audio Transmission Disable
• RTP Streaming 3
Video Size 320x180 JPEG
Frame Rate 15
Multicast Address 0.0.0.0
Multicast Port Number 0
Multicast TTL 1
Audio Transmission Disable
• RTP Streaming 4
Video Size 320x180 JPEG
Frame Rate 30
Multicast Address 0.0.0.0
Multicast Port Number 0
Multicast TTL 1
Audio Transmission Disable
• RTP Streaming 5
Video Size H.264(1)
Frame rate 5
Multicast Address 0.0.0.0
Multicast Port Number 0
Multicast TTL 1
Audio Transmission Disable
• Video Record Setting
Video Record Action Upload
• General Upload
Upload Upload Disabled
Video Format JPEG
Frame Rate 1
Pre-event Buffer (number of
frames)
0
Post-event Buffer (number of
frames)
0
Pre-event Buffer (sec) 0
Item Setting
R11
M641
M741
R11
M641
M741
R11
M641
M741
R11
M641
M741
R11
M641
M741
