74
[Video Quality]
You can select the video quality if [Bit Rate Control] is set to [Do not use bit rate control].
Greater values have higher quality.
[Frame Rate (fps)]
Select the video frame rate.
[I Frame Interval (sec)]
Select the I frame interval (sec) for H.264 video.
H.264(2)
Settings for H.264(2) video transmitted from the camera.
H.264(2) video can be displayed using Admin Viewer and RM-Lite Viewer. It cannot be used for upload, memory card
recording, or by VB Viewer.
The video sizes that can be selected depend on the [Video Size Set] setting.
[H.264(2)]
Select [Enable] to dual stream H.264 video.
[Video Size], [Bit Rate Control], [Target Bit Rate (kbps)], [Video Quality], [Frame Rate (fps)], [I Frame Interval (sec)]
Please refer to each setting in “H.264(1)”.
• When [H.264(1)] is used for memory card recording and upload, the following restrictions apply to the [H.264(1)] setting.
– [Bit Rate Control]: [Use bit rate control] only
– [Target Bit Rate (kbps)]: [3072] or less
– [I Frame Interval (sec)]: either [0.5], [1], or [1.5]
• The included RM-Lite cannot record H.264 video.
• When dual streaming H.264 videos, setting the video size for H.264(1) and H.264(2) to the following combinations restricts the frame
rate to a maximum of 15 fps. For all other combinations, a frame rate of up to 30 fps can be selected.
• The included RM-Lite cannot record H.264 video.
H.264(1) H.264(2)
1280 x 960 1280 x 960
1280 x 720 1280 x 720
