62-11785 5–6
11. To change a value selection screen, press the “=” key with the desired Configuration sub-menu highlighted
as in Sample Screen A. The individual Configurations within the sub-menu will display as in Sample Screen
B. Press the ▲ or ▼ key to scroll through the individual Configurations. The individual Configurations will
highlight as the list is scrolled.
12. With the desired individual Configuration highlighted, press the “=” key. The highlight will move to the pres-
ent setting. As in Sample Screen C. Press the ▲ or ▼ key to scroll through the available settings. With the
desired setting highlighted, press the “=” key to select. Refer to Table 5–1, for information on the settings in
each sub-menu and resultant System actions.
13. Continue as above to enter additional sub-menus and set additional individual Configurations as required.
NOTICE
Technician Mode should be canceled when work is complete. If Technician Mode is not
canceled, Technician Mode will be available for 60 minutes after the last key press without
requiring a code, even after placing the SROS in the OFF and then back in the RUN/STOP
position.
14. Once activity requiring use of Technician Mode is complete, Technician Mode should be manually canceled,
refer to Figure 5.1.
CONFIGURATION SETTINGS (5 OF 10)
ALARM SETTINGS
BACK
EXIT
HOUR METERS
OTHER SETTINGS
RAIL SETTINGS
CONFIGURATION SETTINGS (1 OF 3)
CONFIGURATION 1
BACK
EXIT
CONFIGURATION 3
CONFIGURATION 2
SELECTION
SELECTION
SELECTION
CONFIGURATION SETTINGS (1 OF 3)
CONFIGURATION 1
BACK
EXIT
CONFIGURATION 3
CONFIGURATION 2
END OF LIST
SELECTION
SELECTION
SELECTION
Sample Screen A Sample Screen B Sample Screen C
